Perkins 1100 Series Engine

Perkins 1100 Series Engine

View

View

Perkins 1100 Series Engine

Interview

Select the number of specifications

Please check the product information you want!
WhatsApp me

Product Detail

1100A Series: EU Stage I / EPA Tier 1

Model

Cylinders

Power

Control

Maximum torque

1104A

4

63.5-80.5 kW (85.2-108 hp)

Mechanical

293-404 Nm

(216-298 Ib.ft)

1100C Series: EU Stage II / EPA Tier 2

Model

Cylinders

Power

Control

Maximum torque

1103C

3

43-55 kW

(57.7-73.8 hp)

Mechanical

222-291 Nm

(164-215 Ib.ft)

1104C

4

64-97 kW

(85.8-130.1 hp)

Mechanical

308-500 Nm

(227-369 Ib.ft)

1106C

6

105-162 kW

(140-220 hp)

Mechanical

650-932 Nm
(479.4-687.4Ib.ft)

The 1100 Series gives you:

• A common platform engine designed for a range of markets

• Available in both mechanical and electronic variants

• High power density combined with excellent torque

• Low noise

• Optimum fuel consumption for cost savings

• A huge range of options to tailor your product to meet your needs

• Low cost of ownership

• Two-year / 3,000 hour warranty (36 months on major components)

• 500 hour service intervals

1100D Series: EU Stage IIIA / EPA Tier 3

Model

Cylinders

Power

Control

Maximum torque

1103D

3

36.9-58kW (49.5-77.8 hp)

Mechanical

196-310 Nm

(145-228.6Ib.ft)

1104D

4

56-83 kW

(75.1-111 hp)

Mechanical

265-418Nm (195-308 Ib.ft)

1104D

4

74.5-106 kW

(99.9-142 hp)

Electronic

420-556 Nm

(309-410 Ib.ft)

1106D

6

89-205 kW

(119-275 hp)

Electronic

545-1050 Nm

(402-774 Ib.ft)
